DMB-AQ470 Industrial Motherboard with Intel® 10/11th Gen Core™ i3/i5/i7/i9 CPU, Q470 Chipset, 2× PCIeX16, 3× PCIeX4, 2× PCI, 6× COM, 13× USB, 2× LAN
● Supports Intel® 10/11th Gen Core™ i3/i5/i7/i9 Processor
● Adopting Intel® Q470 Chipset
● 6x COM, 7x USB2.0, 6x USB3.0, 2x GbE LAN
● 1x VGA, 1x HDMI, 1x eDP and 1x DVI, support triple display
● 2x PCIex 16, 3x PCIe x4, 2x PCI
● Supports vPro, AMT, RAID, TPM 2.0, Case Open
▌Specifications
| Model | DMB-AQ470 | |
| CPU | Support Intel® 10/11th Gen Core™ / Pentium/ Celeron Desktop CPU, LGA1200 Support MAX CPU TDP: Deca-Core 125W |
|
| Chipset | Intel® Comet Lake, Q470, TDP 6W | |
| Display [1] | 1× DVI-D (DVI-I): Support DVI-D, max resolution up to 1920×1200@60Hz 1× HDMI 1.4b (TYPE-A): up to 4096×2160@30Hz 1× VGA(DB15/F): max resolution up to 1920×1200@60Hz 1× eDP (Header): max resolution up to 4096×2304@60Hz |
|
| Memory[2] | Support DDR4-2400/2666/2933/3200MHz, 4× Non-ECC U-DIMM Slot, Up to 128GB | |
| Storage | supports RST RAID 0,1,5,10, 4× SATA3.0 7P Connector 1× M.2 Key-M Slot(PCle x4 NVMe/SATA SSD Auto Detect, 2242/2280) |
|
| Ethernet | RJ45 USB1(RJ45):1× 1219-LM GBE LAN Chip (10/100/1000 Mbps, RJ45) RJ45_USB2(RJ45):1× 1210 GBE LAN Chip (10/100/1000 Mbps, RJ45) |
|
| Audio | Realtek HDA Codec, 1× Front Audio Header (Line-Out + MIC) 1× SPDIF Out Header 1× Line-out + Line-in + MIC 3.5mm Jack |
|
| Expansion Slots | 2× PCI Slot 1× Mini PCI-E Slot (WIFI+4G/3G, with 1× Full-Size SIM Card Slot) 1× PCICLK 66MHz Enable/Disable Select Jumper 1× PCI-E Signal Select Jumper 1× PCI-E 16x Slot (PCle 16X GEN3 [5] 1× PCI-E 16x Slot (PCle 8X GEN3, noresources by default) [5] 3× PCI-E 4x Slot(PCle 4X GEN3) |
|
| COM | 1× RS232(COM1, DB9/M) 3× RS232 (COM2 i5/6, Header) 1× RS232/RS422/RS485(COM3, Header) 1× RS232/RS485(COM4, Header) |
|
| USB | 4× USB3.0 (TYPE-A, Rear lO) 2× USB3.0(Header, Internal) 2× USB2.0(TYPE-A, Rear lO) 1× USB2.0 (ver:cal TYEP-A, Internal) 4× USB2.0(Header, Internal) |
|
| Other Ports | 8× GPIO 1× PS/2 Connector (Keyboard & Mouse) 1× Front Panel Header (HDD LED+PWR LED+PWR ON+RESET) 1× Port80 Debug Header 1× SMBUS Header 2× System FAN Header 1× CPU FAN Header 1× Case Open Header 1× CMos Clear Jumper 1× AT or ATX Select Jumper1*ME Flash Header 1× Data Burning Header |
|
| System | Windows 10(64 bit),Linux | |
| Temperature | Storage: -20~75°C Operating: 0~60°C |
|
| BIOS | AMI UEFI BIOS(Support Watchdog Timer) | |
| Power Supply | ATX Standard (24P+8P+4P) 1× ATX4P CPU Power Input Connector 1× ATX 8P CPU Power Input Connector 1× ATX 24PPower Input Connector |
|
| Factor | 305mm× 220mm | |
| TPM | SLB 9670VQ2.0,TPM2.0 (Not onboard by default), Support Intel PTT Default | |
Notes:
[1]: Chipset can be customized into Intel ® W480/Q470E/W480E.
[2j:Intel ® Q47OW480/Q470E/W480E supports three independent displays.
[3]:The maximum memory frequency depends on CPU. Only Intel@ W480W48OE supports ECC.
[4]:R.J45_USB1(R.45)1219-LMsupports Intel AMT 12.0 and Intel vPro competent. R.J45_USB2(R.45)supports l210 by defaultand can support i211 if specified.
[5]: When using Q470, PCIEX16_SLOT1-2 slot support PCIE 16x or dual PCIE 8x is Selected by ‘PCIE Signal SelectJumper'(J_PEG_CFG1, Loca: on 33). lt also can support auto detected if specified.(BOM selec: on)When using H70, it just supportPCIEx16_SLOT1.
