DPM-1101 10.1″ Industrial Touch Monitor with Capacitive or Resistive Touch Screen
● 10.1″ LED-backlit LCD with capacitive or resistive touch screen
● 1x VGA, 1x DVI, 1x DP/HDMI, 1x USB2.0
● DC-IN 12 to 24V
● Supports VESA 75 mount and panel mount
● IP65 compliant front panel
The DPM-1101 is an 10.1-inch widescreen industrial monitor designed for industrial applications. It features a projected capacitive multi-touch or 5-wire resistive touchscreen, housed within a highly durable metal casing, providing front panel IP65-rated protection from water and dust ingress. It supports three signal interfaces via VGA, DP/HDMI, and DVI. Furthermore, the ultra-thin design of the DPM-1101 enables both VESA 75 mount and panel mount installation, simplifying the installation process in different applications.
▌Specifications
Display | |
Size | 10.1 inch |
Touch Type | Projected capacitive multi touch/5-wire resistive touch (optional) |
Transmittance | 87% (capacitive) / 80% (resistive) |
Control Interface | USB |
Surface Hardness | ≥7H ≥3H |
Resolution | 1920 x 800 |
Luminance | 350 nits |
Contrast Ratio | 1000: 1 |
View Angles | 80 (left), 80 (right), 80 (up), 80 (down) |
LED Lifetime | 25,000 hrs |
Color | 16.7M |
I/O Ports | |
USB | 1x USB 2.0 |
Display | 1x DP/HDMI (select one), 1x VGA, 1x DVI |
Power | |
Button | Yes |
DC Input | 12 to 24VDC |
Power Consumption | 10W |
Power Connector | Button |
Remote Power On/Of | 1x Remote switch connector |
PowerAdaptor | AC-DC, 12V@5A, 60W |
Mechanical | |
Dimensions (W x D x H) | 261.5x 174.6 x 29 mm (10.3 x 6.9 x 1.5 inches) |
Weight (N.W.) | 1.1 kg (4 lbs) |
Mounting Mode | Panel mount, wall mount bracket VESA 75 |
Material | Aluminum alloy panel, all-metal chassis |
Environment | |
Operating Temperature | -10 to 50℃ (14 to 122°F) |
Storage Temperature | -20 to 60℃ (-4 to 140°F) |
Relative Humidity | 10% to 95% @ 40°C (104°F), non-condensing |
Vibration | 5-500Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis |
IP Rating | IP65 compliant (for front panel) |
Certification | |
EMC | CE, FCC |
